Meet the soon-to-be-released Mutoh XpertJet 1682UR. Built on Mutoh’s award-winning latest-generation XpertJet print platform, the XPJ-1682UR is a 64” (1625mm) high-productivity UV LED printer with dual print heads, NEW 4” UV-Lamps and a sleek new black design.
Powered by Mutoh’s new US61 series CMYK, White and Varnish inks the printer is built with health in mind. Free of SVCH and Greenguard Gold certified, it ensures the XPJ-1682UR’s output is suited for childcare, healthcare and the most stringent health conscious installations.
Printer Features:
- White ink for increased versatility printing on clear and coloured media
- Varnish ink for creating premium effects and embossed finishes
- Instant dry prints for immediate finishing and delivery
- 5 layer printing in one pass for high block-out double sided prints
- 4 layer printing for backlit signs that change designs with lights turned on and off
- High quality production speeds up to 13.4 m²/h (top print speeds up to 26.5 m²/h)
- US61 ink with 200% ink stretchability
- Print Applications: Point of Sale, Premium Advertising Graphics, Wall & Floor Graphics, Indoor & Outdoor Signage, Backlit Prints, Window Graphics, Event and Exhibition Graphics, Stickers, Labels and Packaging Prototypes
- Ideal for: Anyone chasing a versatile solution with the capability to achieve unique results
Printer Specifications:
- Number of print heads: Dual Staggered Print Heads
- Printing method: Two 8-channel Monoblock Piezo Electric Print Heads
- Curing Method: Two 4” (101.6mm) UV-LED Lamps
- RIP software: Mutoh’s own VerteLith RIP Software
- Maximum printing width: 1615mm
- Media Width: 1625mm
- Variable Head Heights: Low : 0.3mm, Mid : 0.8mm, High : 1.3mm
- Media core size: 50mm (2 inch) or 75mm (3 inch)
- Ink: US61 UV-LED 800ml ink bags
- Ink Combination: 4 colour CMYK, 5 Colour CMYK+Wh, or 6 colour CMYK+WhVa
- Ink Safety: Greenguard Gold Certified
- Print Resolution: Up to 1440x1440dpi
- Power Requirements: AC 100-120V ±10% / 200-240V ±10%, 50/60Hz ±1Hz
- Environmental Conditions: Operating temperature 20-32°C, humidity 40-60% (no condensation)
- Dimensions: 2770mm (W) x 895mm (D) x 1504mm (H)
- Total weight: 181kg
- Engineered & manufactured in Japan.
- 1 Year Labour Warranty
- 3 Year Parts Warranty
